PMC-1202 (EV Kit)

Linear Motor

PMC_1202_complete

Specifications

Characteristic
Units Value
Driving Frequency kHz 25 - 100
Drive Voltage V 16 - 65
Drive Duty % 10 - 40
PC Interface - USB
Supply Power VDC, A 5, 1
Monitoring - PC Program
Size mm 25W x 65L x 10H

Communications

Characteristic
Units Value
Baud Rate bps 115200
Transmission Code - ASCII
Data length bit 8
Stop bit length bit 1
Parity Check - Nil
Data Classification - STX, ETX
Connection - Serial over USB/RS232

Features

The TULA EV-Kit helps the user to understand the basic characteristics of the TULA by changing the duty ratio, driving voltage and driving frequsncy. The purpose of the EV-Kit is to assist in the developement of the user's application of the TULA.

  • Controls the TULA35, TULA50, and TULA70 motors
  • Precision position control
  • High precision achieved with an optical encoder
  • Open pulse drive
  • Auto tuning
  • External digital pulse command of step/dir
  • Command input via Serial over USB
  • Analog control input (0 - 3.3V, Option)

Block Diagram for PMC-1202

The following is a block diagram to illustrate the connections for the PMC-1202 EV Kit

PMC1202_diag_med2

How to Order

The PMC-1202 can be purchased with any of the TULA motors. The Minimum Order Quantity (MOQ) of the EV Kit is one unit when purchased with the motors.

The Minimum Order Quantity (MOQ) for any of the TULA motors is 5 units.

PMC-1202 EV Kit Options

Part
Description
Price (1)Price (2-5)
PMC_1202_sm

PMC-1202
EV Kit

$ 650.00
$575.00
pdf-icon_smTULA Piezoelectric Technologies Catalog (pdf)



More Information
